The AGM-88 HARM (High-speed Anti-Radiation Missile) is a tactical, air-to-surface anti-radiation missile designed to home in on electronic transmissions coming from surface-to-air radar systems. It was originally developed by Texas Instruments as a replacement for the AGM-45 Shrike and AGM-78 Standard ARM system. Production was later taken over by Raytheon Corporation when it purchased the defense production business of Texas Instruments.
Variants
AGM-88E AARGM
The AGM-88E Advanced Antiradiation Guided Missile (AARGM) has an updated guidance section and modified control section, along with the rocket motor and warhead section, wings, and fins from the AGM-88 HARM. It utilizes millimeter-wave radar for precise terminal guidance, countering the enemy's radar shut-down capability, and has the ability to transmit images of the target before impact. Northrop Grumman took control of the AARGM program after acquiring Orbital ATK in 2018. The AGM-88E is in use by the US Navy, US Marine Corps, Italian Air Force, and German Air Force.
In June 2003, Orbital ATK was awarded a $223m contract to develop the AARGM. Subsequently, in November 2005, the Italian Ministry of Defense and the US Department of Defense entered into a memorandum of agreement to jointly fund the project.
The U.S. Navy demonstrated the AARGM's capability during Initial Operational Test and Evaluation (IOT&E) in spring 2012 with live firing of 12 missiles. Aircrew and maintenance training with live missiles was completed in June.
Photo Gallery
Texas Instruments Incorporated
AGM-88 HARM
(High-speed Anti-Radiation Missile)
Produced 1983–present
Texas Instruments Incorporated
AGM-88 HARM (High-speed Anti-Radiation Missile)
Produced 1983–present
-
-
-
-
AGM-88 HARM (High-speed Anti-Radiation Missile)
Specifications Mass - 796 lb (361 kg)
- AGM-88G – 1,030 lb (467 kg)
Length - 13 ft 8 in (4.17 m)
- AGM-88G – 13 ft 4 in (4.06 m)
Diameter - 10 in (254 mm)
- AGM-88G – 11.5 in (292 mm)
Wingspan 3 ft 8 in (1.13 m)
Warhead WAU-7/B blast-fragmentation warhead Warhead weight 150 lb (68 kg)
-
-
-
Engine Thiokol SR113-TC-1 dual-thrust rocket engine Operationalrange - Low-level — 13 nmi (25 km)
- Medium-level — 43 nmi (80 km)
- Standoff — 80 nmi (148 km)
- AGM-88G — 160 nmi (300 km)
Maximum speed Mach 2.9 (987 m/s; 3238 ft/s) Launchplatform F-4G, EA-6B, F-15E, F-16, F/A-18A/B/C/D, F/A-18/E/F, EA-18G, Tornado IDS/ECR, F-35, MiG-29, Su-27
