BK 27 (also BK27 or BK-27)
is a 27 mm (1.063 in) Cannon
In service 1977–present
BK 27 (also BK27 or BK-27) is a 27 mm cannon
 |
|
| Type | Revolver cannon |
|---|---|
| Place of origin | Germany |
| Service history | |
| Used by | See operators |
| Production history | |
| Designer | Mauser (now Rheinmetall) |
| Designed | 1976 |
| Manufacturer | Mauser (now Rheinmetall) |
| Produced | 1977–present |
| No. built | 3,100~ |
|
|||||
|---|---|---|---|---|---|
.
History BK 27 (also BK27 or BK-27) (German abbreviation for Bordkanone,
"on-board cannon") is a 27 mm (1.063 in)
In service 1977–present
The BK 27 (also BK27 or BK-27) (German abbreviation for Bordkanone, "on-board cannon") is a 27 mm (1.063 in) caliber revolver cannon manufactured by Mauser (now part of Rheinmetall) of Germany. It was developed in the late 1960s for the MRCA (Multi Role Combat Aircraft) program that ultimately became the Panavia Tornado. The BK 27 is a gas-operated cannon firing a series of 27×145 mm cartridges with a typical projectile weight of 260 g (9.2 oz), and a total weight for the complete round of 516 g (1.14 lb). Most models use a linked feed system for the ammunition; however, the Eurofighter Typhoon makes use of a specially developed variant of the BK 27 that uses a linkless feed system instead, which is intended to improve reliability
Specifications
- Type: single-barrel, five chamber revolver cannon
- Caliber: 27 mm × 145 (1.063 in)
- Operation: revolver
- Length: 2.31 m (7 ft 7 in)
- Weight (complete): 100 kg (220 lb)
- Rate of fire: 1,000-1,700 rpm selectable (+/− 100 rpm)
- Muzzle velocity: 1,100 m/s (3,600 ft/s)
- Muzzle energy: ≈157,300 Joules
- Projectile weight: 260 g (9.2 oz)
See also
- Oerlikon KCA - comparable Swiss design: 30×173mm NATO
- GIAT 30 - comparable French design: 30×150mm and 30×113mm
- VENOM LR 30 mm – comparable British design, 21st century 113mm-long derivative of ADEN
- DEFA cannon - comparable older French design: 30×113mm
- ADEN cannon – comparable older British design: 30×111mm
- R-23 cannon – comparable Russian design: 23mm×260mm (telescoped)
- M39 cannon – comparable US design: 20×102mm
Operational history
In his book Typhoon, former RAF pilot Mike Sutton reported his 27 mm cannon jamming during a strafing run in Syria, against ISIS targets, while supporting Allied ground units. According to his book, the Typhoon was to be built, originally, without an internal gun, like the F-4 Phantom and the Harrier.
Photo Gallery
BK 27 (also BK27 or BK-27) (German abbreviation for Bordkanone,
"on-board cannon") is a 27 mm (1.063 in)
In service 1977–present
BK 27 (also BK27 or BK-27) (German abbreviation for Bordkanone, "on-board cannon") is a 27 mm (1.063 in) In service 1977–present
-
-
Specifications Mass 100 kg Length 2.31 m (7 ft 7 in) Barrel length 1.73 m (5 ft 8 in)
Shell 27×145 mm Caliber 27 mm (1.063 in) caliber Barrels Single barrel Action five-chamber revolver Rate of fire 1,000–1,700 rpm (+/− 100 rpm), selectable Muzzle velocity 1,100 m/s (3,600 ft/s) Maximum firing range Air targets: 2,500 meters Surface targets: 4,000 meters
High speed naval targets: 2,500 meters
-
