Operational French Army MH.1521M Broussard at Toussus-le-Noble airfield in 1965
Role	Six-seat utility monoplane
National origin	France
Manufacturer	Avions Max Holste
First flight	1952
Introduction	1954
Retired	1993 (French army)
Primary user	French Army
Number built	396

Following the end of the Second World War, Avions Max Holste designed and built a new two-seat trainer and tourer aircraft, the Max Holste MH.52, of which only small numbers were built. Holste then responded to a French Army requirement for an artillery spotter aircraft for a lightweight liaison and observation aircraft. The resulting design, the MH.152, had a fuselage based on that of the MH.52 and a high-mounted wing. It was powered by a 220 horsepower (160 kW) Salmson 8 As.04 engine and had an enclosed, fully-glazed cabin seating a pilot and four passengers. A prototype flew on 12 June 1951. While it demonstrated good short-field performance, the French Army's needs had changed, with it now requiring a robust utility aircraft similar to the de Havilland Canada DHC-2 Beaver

The Max Holste MH.1521 Broussard is a 1950s French six-seat utility monoplane designed by Max Holste to meet a French Army requirement.

Avions Marcel Dassault-Breguet Aviation

Dassault Aviation Avions Max Holste
Max Holste MH.1521 Broussard

General Info

- Crew: 1-2
- Capacity: 4-5 passengers
- Length: 8.65 m (28 ft 5 in)
- Wingspan: 13.75 m (45 ft 1 in)
- Height: 3.67 m (12 ft 0 in)
- Wing area: 25.2 m² (271 sq ft)

Powerplant

Empty weight: 1,650 kg (3,638 lb) equipped
Gross weight: 2,700 kg (5,952 lb)
Powerplant: 1 × Pratt & Whitney R-985-AN-1 9-cylinder air-cooled radial piston engine, 336 kW (451 hp)
Propellers: 2-bladed Hamilton Standard 2.D.30 constant-speed propeller

Specifications

Maximum speed: 259 km/h (161 mph, 140 kn) at 1,000 m (3,300 ft)
Cruise speed: 228 km/h (142 mph, 123 kn)
Stall speed: 92.6 km/h (57.5 mph, 50.0 kn)
Rate of climb: 3.99 m/s (785 ft/min) at sea level
Take-off run: 200 m (660 ft)

Comparable aircraft

- - De Havilland Canada Beaver
