General information
Type	Airliner
Manufacturer	Convair
Status	In limited service
Primary users	American Airlines (historical)^[1]Zantop International Airlines (historical), Air Chathams (historical)
Number built	1076 (Convair) 10 (Canadair) 1086 (total)
History
Manufactured	1947–1954
Introduction date	February 29, 1948 with American Airlines
First flight	March 16, 1947
Variants	Convair C-131 Samaritan Canadair CC-109 Cosmopolitan

The Convair CV-240 is an American airliner that Convair manufactured from 1947 to 1954, initially as a possible replacement for the ubiquitous Douglas DC-3. Featuring a more modern design with cabin pressurization, the 240 series made some inroads as a commercial airliner, and had a long development cycle that produced various civil and military variants. Though reduced in numbers by attrition, various forms of the "Convairliners" continue to fly in the 21st century.

Design and development

The design began with a requirement by American Airlines for an airliner to replace its Douglas DC-3s. Convair's original design, the unpressurised Model 110, was a twin-engine, low-wing monoplane of all-metal construction, with 30 seats. It was powered by Pratt & Whitney R-2800 Double Wasp radial engines. It had a tricycle landing gear, and a ventral airstair for passenger boarding. The prototype Model 110, registration NX90653, first flew on July 8, 1946. By this time, American Airlines had changed the requirements to include pressurization and deemed the design too small. Convair used the first prototype for 240 series development work before it had the plane broken up in 1947.

To meet the requirements of airlines for a pressurized airliner, Convair produced a revised design—the Model 240. This had a longer but thinner fuselage than the Model 110, accommodating 40 passengers in the first pressurized, twin-engined airliner. The 240 first flew on March 16, 194

Famous aircraft Consolidated Convair Vultee Aircraft

Consolidated / Vultee - Convair
Convair CV-240 Nickname Convairliner Manufactured 1947–1954, First flight March 16, 194

General characteristics

Crew: 2 or 3 flight deck crew
Capacity: 40
Length: 74 ft 8 in (22.76 m)
Wingspan: 91 ft 9 in (27.97 m)
Height: 26 ft 11 in (8.20 m)
Wing area: 817 sq ft (75.9 m²)

Powerplant

Empty weight: 25,445 lb (11,542 kg) (revised 29,500 lb (13,381 kg))
Gross weight: 40,500 lb (18,370 kg) (revised 42,500 lb (19,278 kg))
Fuel capacity: 1,000 US gal (3,785.41 L) - 1,550 US gal (5,867.39 L)
Powerplant: 2 × Pratt & Whitney R-2800-CA3 Double Wasp / CA15 / CA18 / CB3 or CB16 18-cyl air-cooled radial engines, 2,400 hp (1,800 kW) each

Specifications

Maximum speed: 315 mph (507 km/h, 274 kn)
Cruise speed: 280 mph (450 km/h, 240 kn) (maximum)
Range: 1,200 mi (1,900 km, 1,000 nmi)
Service ceiling: 16,000 ft (4,900 m)
Rate of climb: 1,520 ft/min (7.7 m/s)

Armament

Special Links Consolidated / Convair Vultee

Links to Youtube & Others

Convair delivered the first production Convairliner to American on February 29, 1948.[7] They delivered a total of 75 to American—and another 50 to Western Airlines, Continental Airlines, Pan American Airways, Lufthansa, KLM, Swissair, Sabena, and Trans Australia Airlines.

Consolidated / Convair Convair CV-240/440

n 1959, a C-131 was the first aircraft to be used as a reduced-gravity aircraft or 'vomit comet', for astronaut training as part of Project Mercury

Youtube Link

n 1959, a C-131 was the first aircraft to be used as a reduced-gravity aircraft or 'vomit comet', for astronaut training as part of Project Mercury

Consolidated / Convair
Convair CV-240
Nickname Convairliner
Manufactured 1947–1954
First flight March 16, 194
