General Info

MD Helicopters
MD 900 Explorer


General information
Type Light twin utility helicopter
Manufacturer McDonnell Douglas Helicopter Systems
MD Helicopters
Status In service
Primary users Mexican NavyLandespolizei
Luxembourg Air Rescue
Drug Enforcement Administration
History
Manufactured 1992–2019
Introduction date 1994
First flight 18 December 1992
.
History Boeing / MD Donnell Douglas
MD 900 Explorer Manufactured 1992–2019
Introduction date 1994 First flight 18 December 1992



The MD Helicopters MD Explorer is a light twin-engined utility helicopter designed and initially produced by the American rotorcraft specialist McDonnell Douglas Helicopter Systems. On 18 December 1992, the maiden flight was conducted, initial certification for the type followed roughly two years later. The initial model, the MD 900, was joined by an improved successor, the MD 902, during the late 1990s. The Explorer is currently produced by MD Helicopters. The helicopter is noted for having no tail rotor, using the NOTAR technology instead, giving its tail a unique appearance and quieter sound profile than a more traditional tail rotor.

In January 1989, McDonnell Douglas Helicopters officially announced the launch of the Explorer, which it initially referred to as the MDX. Amongst other things, the Explorer was the first McDonnell Douglas helicopter to incorporate the NOTAR system from its initial design. McDonnell Douglas partnered with Hawker de Havilland of Australia, which handled the manufacturing of the airframes. A total of ten prototypes were constructed, seven of which being used for ground-based tests. McDonnell Douglas Helicopters became a launch customer for Pratt & Whitney Canada's PW200 turboshaft engines, for which it had an exclusive agreement to power the first 128 Explorers with pairs of PW206As. While plans had been mooted to offer the Turbomeca Arrius powerplant as an alternative option, these were subsequently discarded.

On 18 December 1992, the maiden flight of the Explorer took place, performed by ship #2 (N900MD). On 2 December 1994, Federal Aviation Administration (FAA) certification for the Explorer was granted, permitting its use in North America; Joint Aviation Authorities (JAA) certification was received shortly thereafter. However, certification of the Explorer's instrument flight rules (IFR) capability was protracted due to technical difficulties with integration; in February 1997, FAA certification for IFR operations was finally received.

MD 900 (N900MH) Helicopter Noise Abatement Test, 1996

0

Km

Ceiling

0

Km

MAX RANGE

0

Km/H

Aircraft Speed

0

Max Crew

element
element
Boeing McDonnell Douglas MD helicopters

Boeing / MD Donnell Douglas MD 900 Explorer Manufactured 1992–2019 Introduction date 1994 First flight 18 December 1992

1

General characteristics

  • Crew: 1–2
  • Capacity: Six passengers / 2,565 lb (1,163 kg) internal / 3,000 lb (1,361 kg) slung load
  • Length: 32 ft 4 in (9.86 m)
  • Height: 12 ft 0 in (3.66 m)
2

Powerplant

  • Empty weight: 3,375 lb (1,531 kg)
  • Max takeoff weight: 6,250 lb (2,835 kg) (internal load)
  • 6,900 lb (3,130 kg) (slung load)
plane
3

Specifications

  • Cruise speed: 134 kn (154 mph, 248 km/h) at sea level
  • Never exceed speed: 140 kn (160 mph, 260 km/h)
  • Range: 293 nmi (337 mi, 543 km)
  • Service ceiling: 17,500 ft (5,300 m)
  • Hover ceiling IGE: 11,000 ft (3,400 m) at International Standard Atmosphere
Special Links Boeing/MD MD Explorer i MD900

Links to Youtube & Others

The MD Helicopters MD Explorer is a twin engined utility helicopter; it is equipped with a fully-articulated five-bladed main rotor system as well as bearingless composite flexbeams and rotor hub. The fuselage is composed of composite materials, such as carbonfibre,

MD Helicopters
MD 900 Explorer

Following the 1997 Boeing/McDonnell Douglas' merger, Boeing sold the former MD civil helicopter.

interior

Youtube Link

Following the 1997 Boeing/McDonnell Douglas' merger, Boeing sold the former MD civil helicopter lines to Netherlands-based RDM Holdings in early 1999.

interior
Aircrafttotal : Boeing Helicopters

Read more in Boeing Helicopters
